In modern industrial logistics, managing non-standard, long-format, and heavy-profile commodities—such as structural steel I-beams, PVC/galvanized piping, timber packs, aluminum extrusions, and sheet metal coils—presents a severe spatial optimization challenge. Standard selective pallet racking units are restricted by front vertical upright columns, rendering horizontal insertion of continuous materials impossible.
As a leading cantilever storage system manufacturer and supplier, our engineered cantilever systems eliminate front column obstructions entirely. By utilizing heavy-duty vertical columns rigidly bolted to substantial floor bases, load-bearing arms project horizontally at fixed or adjustable increments, creating an unbroken storage plane capable of accommodating materials of infinite length.
Fabricated from hot-rolled Q235B / Q345B structural steel profiles, offering maximum resistance against vertical compression and dynamic lateral bending moments under asymmetrical loading conditions.
Innovative pivot-arm connections feature hardened alloy steel pins that allow arms to deflect upward when struck by forklift tines, preventing permanent structural column shear and rack damage.
Calculated strictly to FEM 10.2.09 and AS4084 standards, maintaining maximum arm deflection ratios below L/200 under full rated uniformly distributed load (UDL).
Our structural cantilever systems are customized to match exact operational parameters, forklift reach capacities, and warehouse slab load limits:
| Structural Profile Type | Arm Length Range | Per-Arm Load Capacity (UDL) | Column Height Capability | Recommended Applications |
|---|---|---|---|---|
| Light-Duty Roll-Formed | 400 mm – 800 mm | 150 kg – 400 kg | 2,000 mm – 4,000 mm | Light plastics, aluminum trims, conduit tubing, manual hand-picking |
| Medium-Duty C-Profile | 600 mm – 1,200 mm | 400 kg – 900 kg | 3,000 mm – 6,000 mm | Furniture manufacturing, timber boards, medium-gauge steel pipes |
| Heavy-Duty Hot-Rolled H-Beam | 800 mm – 2,000 mm | 1,000 kg – 3,500+ kg | 4,000 mm – 12,000+ mm | Heavy steel plates, structural beams, copper rod coils, heavy machinery stock |
| Extra Heavy Structural (ASRS Integrated) | 1,000 mm – 2,400 mm | 3,500 kg – 6,000 kg | Up to 24,000 mm | Automated crane-operated tube logistics, high-density metal service centers |
Operating from Shah Alam, Selangor, and supplying heavy industry across Malaysia, Singapore, and international industrial hubs, My Interack Sdn. Bhd. combines direct factory production with end-to-end structural engineering. We do not merely act as a supplier; we manage structural design, finite element analysis (FEA), precision cold-roll forming, robotic welding, hot-dip galvanization, and certified site installation under strict ISO-compliant frameworks.
Every structural column and cantilever arm undergoes ultrasonic weld inspection, load deflection testing, and salt-spray powder coat adhesion verification before dispatch.
Trusted by global logistics leaders and industrial conglomerates including Sony EMCS, DHL, Adidas, Perodua, UMW, CEVA Logistics, Kansai Paint, and Econsave.
As global supply chains transition toward automated material handling and higher cube-utilization efficiencies, industrial buyers must evaluate cantilever system acquisitions beyond initial steel tonnage pricing. Procurement managers are increasingly looking at long-term total cost of ownership (TCO), flexible structural scalability, and automated forklift interface capabilities.
Modern procurement strategies favor standardized structural H-beam columns equipped with continuous laser-punched 50mm/75mm adjustment pitch. This enables warehouse operators to adjust arm pitch in-house without structural cutting or welding as stock dimensions change.
With indoor square footage costs rising rapidly, buyers are shifting bulk pipe, lumber, and raw stock storage to outdoor yard spaces. Specification of ISO 1461 compliant hot-dip galvanizing ensures 25+ years of zero-maintenance corrosion protection against tropical humidity and harsh industrial elements.
Narrow Aisle (NA) and Very Narrow Aisle (VNA) cantilever layouts are rapidly replacing standard wide-aisle configurations. Systems designed with floor-mounted guide rails for side-loading forklifts reduce required aisle widths from 4.5 meters down to just 1.8 meters, increasing overall storage density by over 100%.
The evolution of industrial storage racking is tied directly to the rise of Smart Warehousing and Logistics 4.0. Traditional passive steel frames are evolving into intelligent, sensor-monitored material management ecosystems.
Next-generation heavy-duty cantilever columns are being embedded with IoT load-cell strain gauges. These sensors provide continuous telemetry to warehouse management software (WMS), alerting facility managers if dynamic forklift impacts occur or if an arm exceeds its calculated moment deflection limit.
For large-scale metal distribution centers and automated pipe logistics, cantilever systems are being integrated with automated shuttle stacker cranes. Crane forks fitted with multi-stage telescopic arms retrieve long bundles up to 12 meters in length at speeds exceeding 2 meters per second, operating safely in high-bay structures up to 24 meters in height.
To support mixed-inventory fulfillment, modern cantilever design incorporates drop-in wire mesh decks, steel grating, or continuous support arms. This allows warehouse managers to store both continuous long pipes and standard pallets on the same arm tier without buying separate racking systems.
Direct technical guidance from our engineering team regarding design, installation, compliance, and customization.
Contact our structural storage engineers today for layout optimization, load calculation analysis, and direct manufacturer pricing for your facility.
