Engineering Excellence for Light Duty Warehousing
The 100 Series Value Rack by My Interack is engineered for high-efficiency commercial storage, stockrooms, retail sorting facilities, and document archives. Constructed with precision-slotted cold-rolled steel, it delivers unmatched versatility and swift tool-free installation without nuts, bolts, or complex hardware.
Standard Technical Data Sheet
Standard dimensions and loading limits engineered to satisfy international B2B storage and safety regulations.
| Parameter | Standard Specification | Heavy Option / Custom Range |
|---|---|---|
| Load Capacity (UDL) | 100 kg – 200 kg per shelf level | Up to 300 kg per shelf level (with stiffener bars) |
| Standard Upright Heights | 1,500 mm / 1,800 mm / 2,100 mm | 2,400 mm – 3,000 mm customized |
| Available Bay Widths | 900 mm / 1,200 mm / 1,500 mm | 1,800 mm extended span |
| Standard Depths | 300 mm / 450 mm / 600 mm | 800 mm / 900 mm for double-entry |
| Surface Treatment | Anti-corrosive thermoset epoxy powder coating | Custom corporate colors / Galvanized finish |
| Decking Panel Material | 9mm / 12mm High-Density Fibreboard (HDF) | Pre-galvanized steel decking / Wire mesh panel |
Rapid Installation
Engineered interlocking connectors eliminate up to 70% of traditional assembly time. Requires no power tools or specialized rigging labor on-site.
Cost-Optimized Steel
High strength-to-weight structural design maximizes vertical space utilization without forcing facility managers to purchase excessive pallet-tier steel.
Global Export Quality
Packaged in compact, sea-freight optimized knockdown cartons for efficient export container loading across ASEAN, Oceania, and global logistics markets.
