Engineered Selective Pallet Racking Solution
The 3000 Series Heavy Duty Selective Pallet Rack is the industry benchmark for universal pallet storage. Engineered for direct 100% selectivity, it provides unhindered access to every single pallet position without rearranging stock, making it optimal for high-throughput distribution hubs, manufacturing staging, and multi-SKU warehousing.
- Immediate 100% SKU Selectivity: Direct forklift pick-and-place access to any pallet level without disturbing adjacent bays.
- Rapid Height Flexibility: Interlocking connector pins and perforated upright columns permit tool-free beam level adjustments.
- Superior Load Ratings: Engineered with certified heavy-gauge roll-formed structural steel supporting up to 4,500 kg per beam level.
- Damage Prevention & Safety: Standardized with safety locking pins, optional column protectors, frame barriers, and wire mesh decking.
- Turnkey Engineering: Designed, manufactured, statically analyzed, and site-installed to international safety compliance.
100% Selectivity
Unrestricted access to every pallet ensures seamless stock rotation, inventory control, and fast cycle times.
Modular Structural Design
Bolted upright trusses paired with roll-formed box beams allow simple reconfiguration and project relocations.
Broad Forklift Compatibility
Engineered for standard counterbalance, reach trucks, and narrow-aisle equipment without bespoke adaptations.
ISO Certified Quality
Manufactured under strict ISO 9001 and ISO 14001 process standards for durable, fatigue-resistant warehouse life.
Technical Specifications & Structural Dimensions
Every 3000 Series installation is tailored around specific pallet weights, warehouse clear heights, slab capacities, and material handling truck turnaround geometry.
| Parameter | Standard Specification | Heavy Duty Specification | Custom / High-Bay Option |
|---|---|---|---|
| Upright Profile Width | 80 mm / 90 mm | 100 mm / 120 mm | 140 mm Heavy-Gauge Uprights |
| Beam Span | 1,350 mm / 2,300 mm / 2,700 mm | 3,300 mm / 3,600 mm / 3,900 mm | Tailored to Custom Pallet Combinations |
| Load Capacity per Level | 1,000 kg – 2,000 kg UDL | 2,000 kg – 3,500 kg UDL | Up to 4,500 kg UDL per pair of beams |
| Bay Clear Height | Up to 6,000 mm | 6,000 mm – 12,000 mm | Up to 15,000 mm+ High Bay |
| Surface Treatment | Epoxy Polyester Powder Coating | Anti-corrosion Powder Coating | Hot-Dip Galvanized for Chillers/Freezers |
| Decking Accessories | Timber pallet supports | Steel wire mesh decks, pallet support bars | Solid steel shelf panels, drum cradles |
Notice: Actual load capacities must be confirmed by structural engineering layout drawings based on upright pitch spacing, bottom beam height clearance, anchor bolt shear ratings, and concrete floor slab thickness.
Technical Procurement Guide
Maximum bay load is governed by the unbraced length of the upright, which is determined by the height from the finished warehouse floor slab to the first beam level. Raising the bottom beam level significantly reduces the frame load rating. Always consult structural load charts provided by My Interack engineering teams.
Selective pallet racking is ideal for third-party logistics (3PL) providers, retail distribution, fast-moving consumer goods (FMCG) storage, and industrial manufacturers operating high-mix, variable SKUs requiring instant accessibility and first-in, first-out (FIFO) inventory flow.
We supply and install heavy-gauge floor-anchored upright protectors, wrap-around post guards, heavy-duty row end frame barriers, rear safety mesh to protect pedestrian pathways, and drop-in wire decking to prevent accidental loose cargo falls.
Frequently Asked Questions
Selective Pallet Rack Malaysia is the most versatile and cost-effective industrial storage racking system available. Constructed using precision-formed vertical upright frames, horizontal structural box beams, and safety locking pins, it permits immediate, unencumbered handling access to every individual stored pallet.
Key operational benefits include: maximizing vertical cube warehouse space, 100% pallet accessibility for quick cycle times, eliminated risk of stock damage seen in double-stack floor storage, simple inventory reconciliation, and compatibility with standard handling trucks.
Yes. Horizontal connector beams adjust vertically on slotted column intervals, easily accommodating variations in pallet height. Beam lengths and frame depths are tailored to suit 1,200 x 1,000mm standard pallets, 1,200 x 800mm Euro pallets, or non-standard industrial containers.
Yes. We provide complete turnkey logistics, structural floor layout CAD design, anchor pull testing, and precision on-site mechanical erection throughout Malaysia and cross-border project sites in Singapore.
Optimize Your Warehouse With Selective Pallet Racking
Submit your warehouse clear height, pallet dimensions, and floor layout plans. Our storage engineers will prepare a high-density, code-compliant pallet rack layout and proposal.
